StarTech HDMI over CAT5 HDBaseT 4K Video Extender Kit ST121HDBTPW

Regular Price $910.79 Special Price $629.97 $692.97
In stock

Manufacturer :Startech

Warranty :24 Months

new

The StarTech ST121HDBTPW Video Extender Kit extends HDMI up to 330 feet (100 Metres) over a single CAT5e or CAT6 cable. The extender supports Ultra HD and Full HD resolutions (4K / 1080p) with support for 3D and the accompanying 7.1 digital audio. For added versatility, both the transmitter and receiver can be powered by the same single power source using Power Over Cable (POC).

Fast delivery
Australia wide service
Australian owned
100% Australian
Lowest price guarantee
100% Guaranteed
Save money save the environment

Special Offers

Rating:
96%
Regular Price $668.01 Special Price $268.05 $294.86

The StarTech ST121HDBTPW Video Extender Kit enables you to extend HDMI audio/video up to 330 feet (100 metres) over a single CAT5e/6 cable. For added versatility, the extender kit supports Power over Cable (POC), which allows power to be sent over the CAT5e/CAT6 cable, powering both the transmitter and receiver with just one adapter. To help you save installation costs, the extender kit can be installed using new or non-existing non-proprietary Ethernet infrastructure wiring with the included mounting brackets. Plus, with support for High-Definition resolutions of up to 1080p and 4K plus the accompanying digital audio, the HDMI extender lets you get the most of your high-end A/V equipment. The HDMI extender kit includes both the local transmitter and remote receiver units - perfect for point-to-point digital signage applications. To add to the maximum extension distance, the HDMI extender supports HDMI cables up to 32ft on both the local and remote ends. The versatility of this video extender makes it an ideal solution for Commercial Display applications in large buildings such as commercial shopping centres, stadiums, schools, and hospitals.

CONDITION

Brand New - A brand-new, unused, unopened, undamaged item in its original packaging.

WARRANTY

This item comes with 24 month manufacturer's warranty.

FEATURES

• 330ft (100m) HDMI over CAT5 extension
• Power over cable (POC)
• Supports CAT5e and CAT6 Ethernet cable
• HDMI transmitter and receiver included
• 1080p and 4K resolution support
• Mounting hardware included
• No software / drivers required

QUICK SPECIFICATIONS

Product Description: HDMI over CAT5 HDBaseT Extender - Power over Cable - Ultra HD 4K - 330 ft (100m)
Product Type: Video Extender Receiver
Number of Network (RJ-45) Ports: 2
Network (RJ-45): Yes
Number of HDMI Inputs: 1
Number of HDMI Outputs: 1
HDMI In: Yes
HDMI Out: Yes
Twisted Pair Cable Standard: Category 6
Media Type Supported: Twisted Pair
Material: Steel
Form Factor: Desktop
Receiver Height: 25 mm
Receiver Width: 67 mm
Receiver Depth: 80 mm
Receiver Weight (Approximate): 423 g
Input Voltage: 220 V AC, 110 V AC
Connectivity Technology: Wired
Daisy Chain: No
Maximum Operating Distance: 100.58 m
Number of Output Devices Supported: 1
Number of Input Devices Supported: 1
Graphics Modes: 4K
Maximum Video Resolution: 4096 x 2160

WHAT'S INCLUDED

• 1x HDMI Extender
• 1x HDMI Receiver
• 4x Mounting brackets
• 2x Foot pad set
• 1x Universal power adapter (NA / EU / UK / AU)
• 2x Grounding wires
• 2x Screw sets
• 1x Instruction manual
