Aruba 6300F 48-port 1GbE Class 4 PoE and 4-port SFP56 Switch JL665A

The Aruba 6300F JL665A is a 48-port 1GbE Class 4 PoE and 4-port SFP56 Switch which is ideal for enterprise network access, aggregation, core and data centre top of rack (ToR) deployments. Created for game-changing operational efficiency with built-in security and resiliency, the 6300 switches provide the foundation for high-performance networks supporting IoT, mobile and cloud applications.

This item comes with a Limited lifetime warranty.

• Stackable Layer 3 switches with BGP, EVPN, VXLAN, VRF, and OSPF with robust security and QoS
• High performance 880 Gbps system switching capacity, 660 MPPS of system throughput and up to 200 Gbps stacking bandwidth
• Compact 1U switches with full density HPE Smart Rate (1/2.5/5GbE) multi-gigabit, 60W PoE and SFP+ models
• Power-to-port switch bundle with back-to-front airflow ideal for data center 1GbE ToR and OOBM deployments
• Built-in high speed 10GbE/25GbE/50GbE uplinks
• Intelligent monitoring, visibility, and remediation with Aruba Network Analytics Engine
• One touch deployment with the Aruba CX Mobile App
• Aruba NetEdit support for automated configuration and verification
• Aruba Dynamic Segmentation enables secure and simple access for users and IoT

• Product Description: HPE Aruba 6300F - switch - 48 ports - managed - rack-mountable
• Device Type: Switch
• Enclosure Type: Front to back airflow rack-mountable 1U
• Subtype: Gigabit Ethernet
• Ports: 48 x 10/100/1000 (PoE+) + 4 x 50 Gigabit Ethernet SFP56
• Power Over Ethernet (PoE): PoE+
• Switching capacity: 496 Gbps
• Switching throughput: 369 Mpps
• 1 Gbps average latency (64-byte packets): 2.28 µs
• 10 Gbps average latency (64-byte packets): 1.46 µs
• 25 Gbps average latency (64-byte packets): 1.9 µs
• 50 Gbps average latency (64-byte packets): 3.49 µs
• Stacking bandwidth: 200 Gbps
• MAC Address Table Size: 32000 entries
• Jumbo Frame Support: 9198 bytes
• Routing Protocol: OSPF, BGP-4, BGP, IGMP, OSPFv2, PIM-DM, IGMPv3, MSDP, MLDv2, MLD, CIDR
• Remote Management Protocol: SNMP 1, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH, XRMON, SFTP
• Encryption Algorithm: SSL, FIPS 140-2
• Authentication Method: Secure Shell (SSH), RADIUS, TACACS+
• Processor: 1 x ARM Cortex-A72: 1.8 GHz
• RAM: 8 GB DDR4 SDRAM
• Flash Memory: 32 GB
• Interfaces: 48 x 1000Base-T RJ-45 PoE+ - 30 W ¦ 4 x 50Gbit LAN SFP56 ¦ 1 x console (USB) Type C ¦ 1 x USB Type A
• Power Device: Internal power supply
• Dimensions (W x D x H): 44.20cm x 32.77cm x 4.32cm
• Weight: 5.10kg

• HPE Aruba 6300F Switch JL665A
• User Guide
