Aten 8-Port PS/2-USB VGA Dual Rail LCD KVM Switch CL5808N-ATA-AU
The Aten CL5808N-ATA-AU is a high-performance dual rail LCD KVM switch designed for efficient server management, offering an integrated 19" LCD console, support for USB and PS/2 interfaces, daisy-chain expansion up to 256 computers, and superior video quality for professional data centre environments.
The Aten CL5808N-ATA-AU 8-Port PS/2-USB VGA Dual Rail LCD KVM Switch is a powerful and space-efficient solution that integrates a 19" dual rail LCD console with versatile PS/2 and USB support, enabling seamless management of up to 256 computers through daisy-chain expansion. Designed for demanding IT environments, it delivers exceptional video clarity, multi-platform compatibility, secure multi-user access, and intuitive control through pushbuttons, hotkeys, and OSD menus. With advanced features such as LED illumination, broadcast mode, Auto Scan, and hot pluggability, this rack-mountable switch ensures reliable, streamlined, and user-friendly server administration.
CONDITION
Brand New - A brand-new, unused, unopened, undamaged item in its original packaging.
WARRANTY
This item comes with a 12-month manufacturer's warranty.
FEATURES
- Exclusive LED illumination light for better visibility in low-light environments
- Integrated 19" LED-backlit LCD console in a Dual Rail housing
- Space-saving design allows one console to control up to 8 computers
- Daisy-chain up to 31 units to manage up to 256 computers
- Dual interface support for PS/2 and USB keyboards and mice
- Hot-pluggable front USB mouse port also functions as a USB peripheral port
- LCD module tilts up to 120° for comfortable viewing
- Console Lock secures the console when not in use
- Multiplatform support: Windows, Linux, Mac, and Sun
- Supports multimedia USB keyboards for Windows, Mac, and Sun
- Auto PS/2 and USB interface detection
- Keyboard and mouse emulation ensures smooth switching and system booting
- External console support for monitor, USB keyboard, and USB mouse
- Superior video performance up to 1280 × 1024 @ 75 Hz
- Front panel buttons, hotkeys, and multilingual OSD for easy computer selection
- Automatic station detection on daisy-chain installations
- Auto reconfiguration of port names when station order changes
- Two-level password security with admin and user accounts
- LCD power button prolongs display life and saves energy
- Auto Scan mode for continuous monitoring
- Broadcast mode sends commands to all connected computers
- Hot pluggable—add or remove computers without powering down
- Beeper on/off control through hotkeys and OSD
- Simultaneous firmware upgrades across daisy-chained switches
- Optional rack mount kits available
- Supports multiple keyboard languages including English, German, Italian, Japanese, Korean, Russian, Spanish, and more
QUICK SPECIFICATIONS
- Computer Connections: Direct: 8 / Maximum: 256 (via Daisy-chain)
- Port Selection: OSD, Hotkey, Pushbutton
- KVM Ports: 8 x SPHD Female (Yellow)
- Daisy Chain Ports: 1 x DB-25 Male
- Firmware Upgrade: 1 x RJ-11 Female
- Power: 1 x IEC 60320/C14
- External Console Ports: 1 x SPHD Male (Yellow)
- External Mouse Port: 1 x USB Type A Female (Front)
- USB Port: 1 x USB Type A Female (Front)
- LCD Panel: 19" TFT-LCD, 1280 × 1024 @ 75 Hz
- Video Resolution: Up to 1920 × 1200 @ 60 Hz; 1280 × 1024 @ 75 Hz
- Scan Interval: 1–255 seconds
- Emulation: PS/2, USB Keyboard/Mouse
- Power Rating: 100–240V AC, 50/60Hz, 1A
- Power Consumption: AC110V: 25.2W; AC220V: 27.2W
- Environmental: Operating 0–50°C; Storage -20–60°C; 0–80% RH
- Housing
The Aten CL5808N-ATA-AU is a high-performance dual rail LCD KVM switch designed for efficient server management, offering an integrated 19" LCD console, support for USB and PS/2 interfaces, daisy-chain expansion up to 256 computers, and superior video quality for professional data centre environments.
