Cisco Catalyst 9200 24-port POE+ Network Essentials Switch DNA License Mandatory C9200-24P-E
Manufacturer :Cisco
Warranty :Limited Lifetime
The Cisco Catalyst 9200 Network Essentials Switch DNA License Mandatory C9200-24P-E is smart switch featuring 24 x 10/100/1000 (PoE+) Ports.
Overseas orders are NOT AVAILABLE.
Special Offers
The Cisco Catalyst 9200 Network Essentials Switch DNA License Mandatory C9200-24P-E is smart switch featuring 24 x 10/100/1000 (PoE+) Ports.
This Cisco Catalyst 9200 Network Essentials Switch C9200-24P-E is part of Catalyst 9200 series switches that provide enterprise-level resiliency, analytics, and assurance to keep your business up and running seamlessly.
You may also check all the networking switch models, we have at The Telecomshop.
CONDITION
Brand New - A brand-new, unused, unopened, undamaged item in its original packaging.
WARRANTY
This item comes with Limited-Lifetime warranty.
FEATURES
• Cisco StackWise Technology
• EIGRP Stub Routing
• Flexible NetFlow (FNF)
• MACsec support
• built-in ASIC
• Control plane protection (CoPP)
• Blue Beacon LED
• Embedded Event Manager (EEM)
• Protocol Independent Multicast (PIM)
• First Hop Security (FHS)
• PVLAN support
• DNA support
• Superior QoS
QUICK SPECIFICATIONS
• Enclosure Type: Rack-mountable
• Subtype: Gigabit Ethernet
• Ports: 24 x 10/100/1000 (PoE+)
• Power Over Ethernet (PoE): PoE+
• Performance: Stacking bandwidth: 160 Gbps ? Switching bandwidth: 128 Gbps ? Forwarding rate: 190.4 Mpps
• Capacity: Virtual networks: 4 ? IPv4 routing table entries: 4000 ? IPv6 routing table entries: 2000 ? ACL scale entries: 1600 ? Packet buffer size: 6 MB ? VLAN IDs: 4096 ? Switched virtual interfaces (SVIs): 1000
• MAC Address Table Size: 32000 entries
• Jumbo Frame Support: 9198 bytes
• Routing Protocol: OSPF, RIP-1, RIP-2, VRRP, PIM-SSM, policy-based routing (PBR), RIPng
• Remote Management Protocol: NETCONF, RESTCONF
• Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at, IEEE 802.3bz
• Power: AC 120/230 V (50 - 60 Hz)
• Power Redundancy: Optional
• Dimensions (WxDxH): 4.4 cm x 44.5 cm x 35 cm
• Weight: 5.5 kg
WHAT'S INCLUDED
• Cisco Catalyst 9200 24-port POE+ Network Essentials Switch DNA License Mandatory C9200-24P-E
• User Guide
Do you have a question about this product? Please call 1800 90 90 99.
| Discontinued | No |
|---|---|
| Manufacturer | Cisco |
| Icon | Label | Description | Type | Size | Download |
|---|---|---|---|---|---|
|
Cisco Catalyst 9200 Data Sheet | 1.8 MB | Download |
