CyberData 011309 Singlewire InformaCast Outdoor Intercom
Manufacturer :CyberData
Warranty :24 Months
Special Offers
The CyberData 011309 is singlewire informaCast outdoor door intercom that provides two-way communication and secure access control for your VoIP phone system. This intercom is suitable for commercial/residential facilities, schools and universities, retail establishments, warehouse and manufacturing plants, SMB, parking garages and shipyards and other establishments that needs secure access control. It supports communication with a single endpoint or over a mass network. It utilizes SIP or InformaCast protocols and manages the intercom's configuration through a web-based user interface. It also supports SRST in Cisco environments.
Brand New - A brand-new, unused, unopened, undamaged item in its original packaging.
WARRANTYThis item comes with 24 months manufcaturer's warranty.
FEATURES
• Optional red/green/blue/white strobe kit connection available (part number 011288)
• Integrates with Network Dual Door Strike Relay Module (part number 011375) and Door Strike Relay Module (part number 011269)
• Now with enhanced acoustic echo canceler
• InformaCast® compliant
• InformaCast® resiliency protocol
• Capable of receiving SingleWire Informacast, SIP and Multicast messages
• Plays audio from Multicast
• PoE 802.3af enabled (Power-over-Ethernet)
• SIP compliant
• Full-duplex voice operation
• Now supports SRST (Survivable Remote Site Telephony) in a Cisco environment
• Streamlined case design
• Optional weather shroud for even greater weather protection (Weather Shroud sold separately)
• Network web management and firmware download
• Network adjustable speaker volume
• Concurrent SIP and multicast paging
• Dry relay contact for auxiliary control
• Door closure and tamper alert signal
• Downloadable alert, ringtones and callout messages
| Ethernet I/F | 10/100 Mbps |
| Protocol | SIP RFC 3261 Compatible and InformCast v4.0 and later |
| Power Input | PoE 802.3af compliant or +8 to +12VDC @ 1000mA Regulated Power Supply |
| Speaker Output | 2 Watts Peak Power |
| On-Board Relay | 1A at 30 VDC |
| Operating Temperature | -40 degrees C to 55 degrees C (-40 degrees F to 131 degrees F) |
| Humidity | 5-95%, non-condensing |
| IP Rating | IP65 |
| Payload Types | G711 A-Law and u-Law, G.722 |
| Dimensions | Length: 5.118 inches [130 mm], Width: 2.252 inches [57.21 mm], Height: 5.118 inches [130 mm] |
| Weight / Boxed Weight | 2.0 lbs. (0.90 kg) / 3.0 lbs. (1.36 kg) |
| Compliance | CE; EMC Directive Class A EN 55032 & EN 55024, LV Safety Directive- EN 60950-1, RoHS Compliant, FCC; Part 15 Class A, Industry Canada; ICES-3 Class A, IEEE 802.3 Compliant |
• 1 x CyberData 011309 Singlewire InformaCast Outdoor Intercom
• User Guide
Do you have a question about this product? Please call 1800 90 90 99.
| Discontinued | No |
|---|---|
| Manufacturer | CyberData |
| MPN | 011309 |
| Icon | Label | Description | Type | Size | Download |
|---|---|---|---|---|---|
|
CyberData 011309 Singlewire InformaCast Outdoor Intercom Data Sheet | 511.3 KB | Download | ||
|
|
CyberData 011309 Singlewire InformaCast Outdoor Intercom Quick Reference | 2.4 MB | Download | ||
|
|
CyberData 011309 Singlewire InformaCast Outdoor Intercom Quick Start Guide | 519.8 KB | Download |
