HPE Aruba Ap-534 Wireless Access Point JZ331A
The HPE Aruba Ap-534 Wireless Access Point JZ331A is a part of the Aruba 530 Series Campus Access Points with IEEE 802.11ax technology that are designed to deliver extreme-performance access for mobile and IoT devices in environments where device density is very high. The Aruba 530 Series uses 802.11ax features to efficiently and simultaneously serve multiple clients and traffic types in dense environments, increasing data rates for both individual device and overall system. The 530 Series supports maximum data rates of 2.4Gbps in the 5GHz band and 1,150Mbps in the 2.4GHz band (for an aggregate peak data rate of 3.55Gbps). Each AP supports up to 1024 associated client devices per radio, making the high-end 802.11ax 530 Series APs ideal for high density environments, such as higher education, K12, retail, hotels and digital workplaces.
The HPE Aruba Ap-534 Wireless Access Point JZ331A is a part of the Aruba 530 Series Campus Access Point with IEEE 802.11ax technology that are designed to deliver extreme-performance access for mobile and IoT devices in environments where device density is very high.
The Aruba 530 Series uses 802.11ax features to efficiently and simultaneously serve multiple clients and traffic types in dense environments, increasing data rates for both individual device and overall system.
The 530 Series supports maximum data rates of 2.4Gbps in the 5GHz band and 1,150Mbps in the 2.4GHz band (for an aggregate peak data rate of 3.55Gbps).
Each AP supports up to 1024 associated client devices per radio, making the high-end 802.11ax 530 Series APs ideal for high-density environments, such as higher education, K12, retail, hotels and digital workplaces.
CONDITION
Brand New - A brand-new, unused, unopened, undamaged item in its original packaging.
WARRANTY
This item comes with a Limited lifetime manufacturer's warranty.
FEATURES
• AI-powered features for wireless RF and client connectivity optimization.
• Dual-radio (dual 4x4 MIMO) 802.11ax AP with up-and downlink OFDMA and Multi-User MIMO (MU-MIMO).
• Supports all mandatory and several optional 802.11ax features, and up to the full 37 OFDMA Resource Units (RUs).
• Maximum data rates of 2.4Gbps in the 5GHz band and 1,150Mbps in the 2.4GHz band (for an aggregate peak data rate of 3.55Gbps).
• Up to 1,024 associated client devices per radio.
• Ideal for high-density environments, such as higher education,K12, retail branches, hotels and digital workplaces.
SPECIFICATIONS
• Device Type: Wireless access poin0 t
• Ruggedized Design: Indoor
• Form Factor: External
• Connectivity Technology: Wireless
• Data Transfer Rate: 2.4 Gbps
• Line Coding Format: CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM, OFDM, 1024 QAM, OFDMA
• Data Link Protocol: IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0, IEEE 802.11ax
• Spread Spectrum Method: OFDM, DSSS, OFDMA
• Frequency Band: 2.4 GHz, 5 GHz
• Performance: Maximum data rate (2.4 GHz): 1150 Mbps ¦ Maximum data rate (5 GHz): 2.4 Gbps ¦ Aggregate bandwidth: 3.55 Gbps
• Capacity: Wireless clients per Wi-Fi radio: 1024 ¦ OFDMA units: 37 ¦ BSSIDs per radio: 16
• Status Indicators: System, status
• Encryption Algorithm: WPA, WPA2, WPA3
• Compliant Standards: IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.11ac, IEEE 802.3bz, IEEE 802.3bt, IEEE 802.11ax
• Antenna External: detachable
• Antenna Qty: 4
WHAT'S INCLUDED
• HPE Aruba Ap-534 Wireless Access Point JZ331A
• Mounting brackets
• User Guide
Do you have a question about this product? Please call 1800 90 90 99.
TTS-JZ331A
New
10000 Items
Specific References
- MPN
- JZ331A
The HPE Aruba Ap-534 Wireless Access Point JZ331A is a part of the Aruba 530 Series Campus Access Points with IEEE 802.11ax technology that are designed to deliver extreme-performance access for mobile and IoT devices in environments where device density is very high. The Aruba 530 Series uses 802.11ax features to efficiently and simultaneously serve multiple clients and traffic types in dense environments, increasing data rates for both individual device and overall system. The 530 Series supports maximum data rates of 2.4Gbps in the 5GHz band and 1,150Mbps in the 2.4GHz band (for an aggregate peak data rate of 3.55Gbps). Each AP supports up to 1024 associated client devices per radio, making the high-end 802.11ax 530 Series APs ideal for high density environments, such as higher education, K12, retail, hotels and digital workplaces.
