Startech RS232 2 Port Serial-to-IP Ethernet Device Server NETRS2322P
This Startech NETRS2322P 2-port serial device server is a cost-effective way to remotely connect to and manage two serial devices over your typical IP network. The device server integrates two RS232 ports into a rugged metal housing with an extended operating temperature range, so it’s perfect for factory and industrial settings.
If you’re looking for a reliable serial-over-IP control solution, then this Startech NETRS2322P device server can help. With a rugged metal housing and an extended operating temperature range, you can rest assured that the device server can deliver the reliable performance you need, even in harsh environments.
With redundant power input, this dual-port serial device server ensures seamless operation, even in the event of power dips or failures. It features a wide-range, terminal block power input (9~36V DC), and includes a universal power adapter.
Plus, it features two integrated mounting brackets, so you can mount the device server to a surface or a wall as needed, for out-of-the-way installations.
CONDITION
Brand New - A brand-new, unused, unopened, undamaged item in its original packaging.
WARRANTY
This item comes with a 24-months manufacturer's warranty.
FEATURES
• Two RS232 (DB9) serial ports, integrated into a durable, metal housing that’s ideal for industrial environments
• Built-in mounting brackets let you easily install the device server to a wall or surface
• Redundant power input using the provided power adapter, or 9~36V DC terminal block input
• Extended operating temperature range — 0°C to 85°C (32°F to 185°F)
• Up to 460.8Kbps serial baud rate
• Remote management and customization using the provided Windows based VCOM software or the Web interface
• Supports Telnet, ICMP, IP, TCP, UDP, DHCP and BOOTP protocols
• 15kV Air and 8kV contact ESD (Electrostatic Discharge) Protection
• 10/100Mbps RJ45 port that supports IEEE 802.3 (10BASE-T) and IEEE 802.3u (100BASE-TX) protocols
QUICK SPECIFICATIONS
• Product Type: Device Server
• Manufacturer Part Number: NETRS2322P
• Number of Network (RJ-45) Ports: 1
• Network (RJ-45): Yes
• Serial Port: Yes
• Parallel Port: No
• Network (RJ-11): No
• Phone Line (RJ-11): No
• Number of Serial Ports: 2
• PoE (RJ-45) Port: No
• Centronics Port: No
• Media Type Supported: Coaxial Twisted Pair
• Environmentally Friendly: Yes
• TAA Compliant: Yes
• Network Standard: 10/100Base-TX
• Ethernet Technology: Fast Ethernet
• Weight (Approximate): 320.3 g
• Colour: Black
• Form Factor: Wall Mountable
• Height: 22.9 mm
• Width: 81.3 mm
• Depth: 111.8 mm
• Input Voltage: 12 V DC
• Wireless LAN: No
• Compatibility Virtual COM software - Windows® Only: Windows Vista, 7, 8, 8.1, 10, Windows Server® 2008 R2, 2012, 2016, 2019
WHAT'S INCLUDED
• 1 x 2-port serial device server
• 1 x Terminal block (2-wire)
• 1 x Universal power adapter (NA/EU/UK/AU)
• 1 x Software CD
• User Guide
Do you have a question about this product? Please call 1800 90 90 99.
This Startech NETRS2322P 2-port serial device server is a cost-effective way to remotely connect to and manage two serial devices over your typical IP network. The device server integrates two RS232 ports into a rugged metal housing with an extended operating temperature range, so it’s perfect for factory and industrial settings.
